YK圆振筛简介：
圆振筛的运动轨迹呈圆周，做圆形运动，是一种多层数、 新型振动筛。YK系列圆振筛主要由偏心块激振器、筛箱、电动机、及支承装置等组成。采用小振幅，高频率，大倾角结构，使该机筛分效率高、处理量大、寿命长、电耗低、噪音小。它主要适用于选煤、选矿、建材、电力及化工等行业。
主要技术参数:
圆振动筛规格与技术参数：
| 型号 | 筛网层数 | 筛子面积 (m2) | 筛孔尺寸 (mm) | 给料粒度 (mm) | 生产能力 (m3/h) | 振动频率 (r/min) | 倍幅 (mm) | 功率 (kw) | 重量 (kg) |
| 2YK1235 | 2 | 4.2 | 5-50 | 200 | 35-180 | 970 | 7 | 5.5 | 3600 |
| 2YK1245 | 2 | 5.4 | 5-50 | 200 | 35-206 | 970 | 7 | 11 | 4320 |
| 3YK1245 | 3 | 5.4 | 5-50 | 200 | 35-206 | 970 | 8 | 11 | 4460 |
| YK1535 | 1 | 5.25 | 5-50 | 200 | 34-200 | 970 | 8 | 11 | 3355 |
| 3YK1535 | 3 | 5.25 | 5-50 | 400 | 34-200 | 970 | 8 | 15 | 5710 |
| YK1545 | 1 | 6.75 | 5-50 | 400 | 44-258 | 970 | 8 | 11 | 3900 |
| 2YK1545 | 2 | 6.75 | 5-50 | 400 | 44-258 | 970 | 8 | 15 | 4370 |
| 3YK1545 | 3 | 6.75 | 5-50 | 400 | 44-258 | 970 | 8 | 15 | 5832 |
| 3YK1548 | 3 | 7.2 | 5-50 | 400 | 47-275 | 970 | 7 | 15 | 6070 |
| 4YK1548 | 4 | 7.2 | 5-100 | 200 | 47-275 | 730 | 8 | 18.5 | 7090 |
| YK1848 | 1 | 8.8 | 5-100 | 400 | 56-330 | 755 | 11 | 15 | 7122 |
| 2YK1848 | 2 | 8.8 | 5-100 | 400 | 56-330 | 750 | 11 | 15 | 6189 |
| 3YK1848 | 3 | 8.8 | 5-100 | 400 | 56-330 | 970 | 7 | 22 | 6935 |
| 2YK1854 | 2 | 9.72 | 5-100 | 400 | 63-586 | 970 | 7 | 22 | 7602 |
| 3YK1854 | 3 | 9.72 | 5-100 | 400 | 63-586 | 970 | 7 | 22 | 8640 |
| 4YK1854 | 4 | 9.72 | 5-150 | 200 | 32-310 | 12.16 | 8 | 30 | 10530 |
| YK2154 | 1 | 11.3 | 5-100 | 400 | 73-683 | 730 | 8 | 18.5 | 5269 |
| 2YK2154 | 2 | 11.3 | 5-100 | 400 | 73-683 | 730 | 8 | 22 | 7851 |
| 3YK2154 | 3 | 11.3 | 5-100 | 400 | 73-683 | 730 | 8 | 22 | 9857 |
| 2YK2160 | 2 | 12.6 | 5-100 | 400 | 81-720 | 970 | 8 | 30 | 9240 |
| 3YK2160 | 3 | 12.6 | 5-100 | 400 | 81-720 | 970 | 7 | 30 | 12757 |
| 4YK2160 | 4 | 12.6 | 5-100 | 450 | 66-720 | 740 | 8 | 45 | 15125 |
| 2YK2280 | 2 | 17.6 | 5-150 | 400 | 90-750 | 730 | 8 | 30 | 10180 |
| YK2460 | 1 | 14.4 | 5-150 | 400 | 150-810 | 730 | 8 | 22 | 6200 |
| 2YK2460 | 2 | 14.4 | 5-150 | 400 | 150-810 | 730 | 8 | 30 | 8013 |
| 3YK2460 | 3 | 14.4 | 5-150 | 200 | 450-650 | 740 | 8 | 37 | 10762 |
| 4YK2460 | 4 | 14.4 | 5-150 | 200 | 450-650 | 740 | 8 | 45 | 1 |
